Diffuser

Technical data

General data:

Luminaire body:
aluminum
Mounting type:
suspended
Ingress protection IP:
20

Electrical data:

Nominal voltage:
220-240V AC
Nominal freguency:
50-60Hz
Protection class:
I
Dimming:
ON-OFF, DALI Casambi
Power supply:
inside the luminaire

Dane optyczne:

Optical system:
OP- opal diffuser
Light emission:
direct
Light distribution:
symmetrical

Lighting data:

Light source:
LED
Colour rendering index:
CRI>80
Tolerance of luminous flux:
+/-10%

Downloads

Product data sheet Declaration of Conformity Assembly, use and maintance instructions Assembly instructions for central ceiling rose

Product description

The SQUARE suspended luminaire is a compact aluminium lighting profile. This square or rectangle designed luminaire can be used in a wide variety of arrangements. Its modern and uncomplicated construction allows for regular light diffusion. It is also available in surface mounted and suspended version.

  • IP20
  • CE
  • I

Available product colors

Standard:
  • white
    03
  • grey
    06
  • anthracite
    70
  • black
    05

suspension cabels certified fot resistance to vibrations and oscillations



C- colour



E- electronics

0- on-off

D- DALI

C- Casambi

Catalogue code Luminaire light flux Power Effectiveness Color temperature Dimensions UGR
low power: 6015.02EC 3903lm 38W 116lm/W 2700K L=630mm <26
low power: 6015.03EC 4152lm 38W 116lm/W 3000K L=630mm <26
low power: 6015.04EC 4417lm 38W 116lm/W 4000K L=630mm <26
low power: 6016.02EC 5851lm 58W 114lm/W 2700K L=910mm <26
low power: 6016.03EC 6224lm 58W 114lm/W 3000K L=910mm <26
low power: 6016.04EC 6622lm 58W 114lm/W 4000K L=910mm <26
low power: 6017.02EC 7801lm 76W 116lm/W 2700K L=1190mm <26
low power: 6017.03EC 8299lm 76W 116lm/W 3000K L=1190mm <26
low power: 6017.04EC 8829lm 76W 116lm/W 4000K L=1190mm <26
low power: 6018.02EC 9751lm 94W 117lm/W 2700K L=1469mm <26
low power: 6018.03EC 10374lm 94W 117lm/W 3000K L=1469mm <26
low power: 6018.04EC 11036lm 94W 117lm/W 4000K L=1469mm <26
high power: 6019.02EC 5377lm 56W 109lm/W 2700K L=630mm <28
high power: 6019.03EC 5721lm 56W 109lm/W 3000K L=630mm <28
high power: 6019.04EC 6086lm 56W 109lm/W 4000K L=630mm <28
high power: 6020.02EC 8067lm 84W 108lm/W 2700K L=910mm <28
high power: 6020.03EC 8581lm 84W 108lm/W 3000K L=910mm <28
high power: 6020.04EC 9129lm 84W 108lm/W 4000K L=910mm <28
high power: 6021.02EC 10755lm 111W 109lm/W 2700K L=1190mm <28
high power: 6021.03EC 11441lm 111W 109lm/W 3000K L=1190mm <28
high power: 6021.04EC 12172lm 111W 109lm/W 4000K L=1190mm <28
high power: 6022.02EC 13444lm 138W 110lm/W 2700K L=1469mm <28
high power: 6022.03EC 14302lm 138W 110lm/W 3000K L=1469mm <28
high power: 6022.04EC 15215lm 138W 110lm/W 4000K L=1469mm <28
Expand

Accessories

Central ceiling rose Ø140
catalogue number 60.01C
