Technical data
General data:
Mounting type:
suspended
Luminaire body:
aluminum
Operating temperature range:
from -20° to +35°
Lifetime L80B10:
100 000h
Ingress protection IP:
IP20
Optical data:
Light distribution:
symmetrical
Optical system:
lens
Pro:
I
Lighting data:
Type of source:
LED
Electrical data:
Nominal voltage:
230-240V AC
Nominal frequency:
50-60Hz
Dimming:
DALI, Casambi
Available product colors
Standard:
-
white03 finish of the profile -
grey06 finish of the profile -
anthracite70 finish of the profile -
black05 finish of the profile -
greyP1 finish of the material -
dark greyP2 finish of the material -
dark greenP3 finish of the material
E-electronics
D- Dali
C-Casambi
C- colour
L – lenses
50 – 50°
80 – 80°
suspension cables certified for resistance to vibrations and oscillations
| Catalogue code | Luminaire light flux | Power | Effectiveness | Dimensions | UGR |
|---|---|---|---|---|---|
| 1831.0104TWE.00.LC.Cp | 2372lm | 18W | 132lm/W | 1204mm | <15 |
