choose the optic ➔
Technical data
General data:
Mounting:
surface mounted, suspensions
Ingress protection IP:
IP65
Electrical data:
Protection class:
I
Optical data:
Light distribution:
symmetrical
Light emission:
direct
Lighting data:
Colour rendering index:
CRI>80
Light source:
LED
information:
luminaire body:
white finish
we recommend:
using four suspension lines for one luminaire
the power supply:
cable is not icluded and is provided by the customer
suspension cables:
certified for resistance to vibrations and oscilations
Product description
The Extreme Sport industrial luminaire is equipped with an efficient optical system based on a highly polished reflector and a microprismatic diaphragm. Thanks to this, the luminaire provides illumination of the room without glare- glare factor UGR <22. Two optics to choose from, symmetrical and asymmetrical. Housing made from aluminium. The luminaire structure is resistant to mechanical factors- impact protection class IK 09. Application in places such as sports facilities, multi-functional halls, conference rooms. The luminaire is available in surface mounted versions. Suspended version on request.
E- electronics
0- On-Off
D- DALI
Catalogue code | Luminaire light flux | Power | Effectiveness | Color temperature | UGR |
---|---|---|---|---|---|
8001.113E | 16999lm | 150W | 114lm/W | 3000K | <22 |
8001.114E | 18084lm | 150W | 121lm/W | 4000K | <22 |
Accessories
suspension 1500mm
catalogue code 735.01
suspension 4000mm
catalogue code 735.04
