Technical data
General data:
Casing:
sheet steel
Mounting:
suspended
Ingress protection IP:
IP20
Operating temperature range:
from -20℃ to +45℃
Lifetime L80B10:
100 000 h
Electrical data:
Nominal voltage:
220-240V
Nominal freguency:
50-60Hz
Protection class:
I
Contains light source:
yes
Dimming:
DALI, Casambi
Optical data:
Optical system:
lens
Material:
PMMA
Light emission:
direct
Light distribution:
symmetrical
Lenses available:
50°, 80°
Lighting data:
Type of source:
LED
Colour rendering index:
CRI>90
Tolerance of luminous flux:
+/- 10%
Available product colors
Standard:
-
white03 -
black05
C - colour
E- electronics
D-DALI
C-Casambi
L – lenses
50 – 50°
80 – 80°
| Catalogue code | Luminaire light flux | Power | Effectiveness | Color temperature | UGR |
|---|---|---|---|---|---|
| 6111.02ELC | 4071lm | 40W | 110lm/W | 2700K | <17 |
| 6111.03ELC | 4240lm | 40W | 110lm/W | 3000K | <17 |
| 6111.04ELC | 4417lm | 40W | 110lm/W | 4000K | <17 |
