Technical data
General data:
luminaire body:
steel
mounting:
recessed
ingress protection IP:
IP20
operating temperature range:
from -20°C to +40°C
lifetime L80B10:
100 000h
Optical data:
optical system:
reflector
material:
aluminum
light emmission:
symmetrical
light distribution:
direct
Lighting data:
type of source:
LED
colour rendering index:
CRI>90
tolerance of luminous flux:
+/-10%
colour tolerance:
SDCM<3
Electrical data:
nominal voltage:
220-240V AC
nominal frequency:
50-60 Hz
protection class:
II
contains light source:
yes
dimming:
on-off, DALI, CASAMBI
Downloads
Product description
Recessed EXPO fixtures are minimalist, highly functional solutions that seamlessly integrate with ceiling surfaces, providing discreet and efficient lighting. Surface-mounted EXPO fixtures feature easy installation and modern design, making them ideal for spaces requiring visible light sources. Both types of fixtures are available in various power options and beam angles, allowing for customization to individual needs. The products ensure durability and high-quality lighting thanks to advanced LED technology.
Available product colors
Standard:
-
white03 -
grey06 -
anthracite70 -
black05
C- colour
E- electronics
O- on-off
D- DALI
C- CASAMBI
L- beam angle
36 – 36°
60 – 60°
| Catalogue code | Luminaire light flux | Power | Effectiveness | Color temperature | UGR |
|---|---|---|---|---|---|
| 3131.02ELC | 895lm | 8W | 122lm/W | 2700K | <20 |
| 3131.03ELC | 933lm | 8W | 122lm/W | 3000K | <20 |
| 3131.04ELC | 972lm | 8W | 122lm/W | 4000K | <20 |
| 3132.02ELC | 1500lm | 13W | 125lm/W | 2700K | <22 |
| 3132.03ELC | 1562lm | 13W | 125lm/W | 3000K | <22 |
| 3132.04ELC | 1627lm | 13W | 125lm/W | 4000K | <22 |
