Technical data
General data:
Luminaire body:
PC
Mounting type :
surface
Ingress protection IP:
IP65
Operating temperature range :
from -20°C to +60°C
Lifetime L80B10:
100000h
Impact protection IK :
IK08
Optical data:
Nominal voltage :
220-240 V
Nominal frequency :
50Hz
Protection class :
II
Lighting data:
Material :
PC
Light distribution :
symmetrical
Electrical data:
Colour rendering index :
CRI≥80
Colour tolerance SDCM :
≤6 SDCM
Downloads
.jpg)
.jpg)
.jpg)
.jpg)
| Catalogue code | Luminaire light flux | Power | Effectiveness | Color temperature | Dimensions |
|---|---|---|---|---|---|
| EP0007.4 | 2835lm | 17W | 167lm/W | 4000K | 605mm |
| EP0008.4 | 5670lm | 33W | 172lm/W | 4000K | 1205mm |
| EP0009.4 | 7020lm | 41W | 171lm/W | 4000K | 1505mm |
| EP0010.4 | 8910lm | 53W | 168lm/W | 4000K | 1505mm |
| EP0011.4 | 10890lm | 65W | 168lm/W | 4000K | 1505mm |
