choose the height of the luminaire ➔

Technical data

General data:

luminaire body:
aluminum
mounting ty:
mounting base
ingress protection IP:
IP65
operating temperature range:
from -40℃ to +45℃
lifetime L80B10:
100 000 h

Optical data:

optical system:
lens
m:
PMMA
light emmission:
direct
light distribution:
symmetrical

Lighting data:

type of source:
LED
colour rendering index:
>80
tolerance of luminous flux:
+/- 10%

Electrical data:

nominal voltage:
220-240V AC
nominal frequency:
50-60Hz
protection class:
I
contains light source:
yes
dimming:
on/off, DALI
connection:
through

Product description

JUNIOR outdoor bollard is a modern lighting solution designed for urban spaces. Its minimalist form combines elegance and functionality, while the compact head seamlessly integrates into the surroundings. The optical elements are cleverly concealed, creating a subtle and atmospheric lighting effect. The PMMA diffuser ensures even light distribution, enhancing visual comfort.

The JUNIOR bollard is available in four height variants: 160mm, 600mm, 800mm, and 1000mm, with a full 360° light distribution angle. Additionally, the JUNIOR E model is available, featuring an extra socket to enhance functionality and adapt to various user needs.

Both variants are offered in color temperatures of 2700K, 3000K, and 4000K, allowing the light to be tailored to the desired ambiance of the space. Ideal for various public and private areas, including parks, squares, residential estates, promenades, walkways, and parking lots.

Available product colors

Standard:
  • white
    03
  • grey
    06
  • anthracite
    70
  • black
    05

E-electronics
0- On- Off
D- DALI



C - colour

Catalogue code Luminaire light flux Power Effectiveness Color temperature Weight
9493.62EC 467lm 7W 75lm/W 2700K 5,5kg
9493.63EC 497lm 7W 75lm/W 3000K 5,5kg
9493.64EC 528lm 7W 75lm/W 4000K 5,5kg
9494.62EC 933lm 12W 88lm/W 2700K 5,5kg
9494.63EC 993lm 12W 88lm/W 3000K 5,5kg
9494.64EC 1056lm 12W 88lm/W 4000K 5,5kg
9495.62EC 1230lm 19W 73lm/W 2700K 5,5kg
9495.63EC 1309lm 19W 73lm/W 3000K 5,5kg
9495.64EC 1392lm 19W 73lm/W 4000K 5,5kg
