INX 175 SURFACE

Technical data

General data:

Luminaire body:

stainless steel 1.4301, electropolished

Mounting type :

surface mounted

Ingress protection IP:

Operating temperature range :

from -40° to +45°

Lifetime L80B10:

100 000h

Impact protection IK :

Electrical data:

Nominal voltage :

220-240V AC

Nominal frequency :

50-60Hz

Protection class :

Connection :

wire 3x1,5mm², (5x1,5mm² for DALI)

Wiring :

standard

Connection wire :

0,5m

Dimming :

ON-OFF, DALI

Power supply :

inside the luminaire

Optical data:

Optical system :

lens

Material :

PMMA

Aperture:

12mm tempered glass

Light emission :

direct

Light distribution :

symmetrical

Lighting data:

Light source :

LED

Colour temperature :

2700K, 3000K, 4000K(on request: 6500K, amber, red, blue, green)

Colour rendering index :

CRI>80 (on request: CRI>90)

Colour tolerance SDCM :

SDCM<3

Tolerance of luminous flux :

+/-10%

Downloads

Product data sheet LDT files Declaration of conformity Tender text with product name Tender text without product name

Product description

Luminaires from the INX series are designed for operation in the most demanding outdoor environments. Made of electropolished stainless steel 1.4301, they provide maximum resistance to corrosion and salinity, weather conditions, and mechanical damage, while offering a refined, high-quality surface finish. Electropolishing not only enhances the aesthetic of the luminaires but also increases the material’s resistance to dirt and aggressive environmental conditions.

INX 175 Surface is a surface-mounted architectural luminaire designed for installation on hard surfaces. It integrates seamlessly with modern architecture, providing durable and aesthetically pleasing illumination for façades and outdoor spaces. With IP67 ingress protection and IK10 impact resistance, the luminaire can be safely installed along pedestrian routes and in public spaces, ensuring reliable lighting of façades, greenery, and architectural elements even under intensive use. The option to select suitable optics allows precise adjustment of the light’s character and distribution to meet the specific requirements of each project.
