Technical data
General data:
Luminaire body:
aluminum/inox
Mounting type:
in-ground
Ingress protection IP:
67
Operating temperature range:
from -25° to +45°
Lifetime L80B10:
100 000h
Optical data:
Optical system:
lens
Material:
PMMA
Light emmission:
direct
Light distribution:
symmetrical
Lighting data:
Type of source:
LED
Colour rendering index:
CRI>80 (options: CRI>90)
Tolerance of luminous :
+/-10%
Colour tolerance:
SDCM<3
Electrical data:
Nominal voltage:
220-240V AC, 24V DC
Nomina:
50-60Hz, DC
Protection class:
I, III
Contains light source:
yes
Dimming:
ON-OFF
connection:
wire 3x1mm2, 2x1mm2
wiring:
standard
connection wire:
0,5m
power supply:
inside the luminaire
Product description
Naik is an uplight luminaire for easy installation in sidewalks, promenades and squares. Perfect to illuminate building facade and other architectural elements. The IP 67 protection class means that the luminaire perfectly withstands tough weather conditions. The luminaire structure is resistant to mechanical factors – impact resistance class IK 10. Housing made of alumnium, outer ring - stainless steel. 8mm toughened glass. The Naik luminaire makes it possible to design dynamic light scenes.
L – lens
10 – 10°
20 – 20°
40 – 40°
41 – 10°x45° oval horizontal
| Catalogue code | Luminaire light flux | Power | Color temperature | Weight | Box dimensions |
|---|---|---|---|---|---|
| 9467.020L | 120lm | 2W (230V) | 2700K | 0,4kg | 200x200x200mm |
| 9467.030L | 125lm | 2W (230V) | 3000K | 0,4kg | 200x200x200mm |
| 9467.040L | 130lm | 2W (230V) | 4000K | 0,4kg | 200x200x200mm |
| 9468.020L | 240lm | 3W (230V) | 2700K | 0,4kg | 200x200x200mm |
| 9468.030L | 250lm | 3W (230V) | 3000K | 0,4kg | 200x200x200mm |
| 9468.040L | 261lm | 3W (230V) | 4000K | 0,4kg | 200x200x200mm |
| 9468.120L | 240lm | 3W (24V) | 2700K | 0,4kg | 200x200x200mm |
| 9468.130L | 250lm | 3W (24V) | 3000K | 0,4kg | 200x200x200mm |
| 9468.140L | 261lm | 3W (24V) | 4000K | 0,4kg | 200x200x200mm |
Accessories
honeycomb (anti-glare)
90.11
square frame
90.30
connector IP68 3-pole
124.00
embranchment IP67
90.10
