Technical data
General data:
Luminaire body:
aluminum
Mounting type :
on an adjustable holder, to the ground
Ingress protection IP:
67
Operating temperature range :
from -40° to +50°
Lifetime L80B10:
100 000h
Impact protection IK :
10
Electrical data:
Nominal voltage :
220-240V AC
Protection class :
I
Connection :
wire 3x1,5mm2 , DMX-in, DMX-out
Wiring :
through, standard
Connection wire :
0,5m
Dimming :
DMX, DALI
Power supply :
see the instruction in the "Downloads"
Optical data:
Optical system :
lens
Material :
PMMA
Aperture:
toughened glass 12mm thick
Light emission :
direct
Light distribution :
symmetrical, asymmetrical
Lighting data:
Light source :
LED
Tolerance of luminous flux :
+/-10%
Downloads
Available product colors
Standard:
-
white03 -
grey06 -
anthracite70 -
black05
E- electronics
0- on-off
D- Dali
L - beam angle
10 - 10 °
20 - 20 °
30 - 30 °
40 - 40 °
60 - 60 °
41 - 10°x45° oval
8 - 8 ° wall-washing
45 - 45 ° wall-washing
02 - asymmetrical
C - colour
W - wiring
T - through
S - standard
| Catalogue code | Luminaire light flux | Power | Effectiveness | Color temperature |
|---|---|---|---|---|
| 9558.02ELCW | 8476lm | 125W | 70lm/W | 2700K |
| 9558.03ELCW | 8610lm | 125W | 70lm/W | 3000K |
| 9558.04ELCW | 8749lm | 125W | 70lm/W | 4000K |
