Technical data

General data:

luminaire body:
aluminum
mounting type:
foundation
ingress protection IP:
65
operating temperature range:
from -40° to +40°
lifetime L80B10:
100 000h
impact protection IK:
08

Electrical data:

nominal voltage:
220-240V AC
nominal frequency:
50-60Hz
luminaire nominal power:
25W, 38W
protection class:
I
connection:
connector in a box
wiring:
through
dimming:
ON-OFF, DALI
power supply:
inside the luminaire

Optical data:

optical system:
lens
material:
glass
light emission:
direct
light distribution:
symmetrical

Lighting data:

light source:
LED
colour rendering index:
CRI>80
colour tolerance SDCM:
SDCM<3
tolerance of luminous flux:
+/-10%

Downloads

Product data sheet Assembly, use and maintenance instructions declaration of comformity modele 3D LDT files

Product description

Reet is a combination of several functionalities in outdoor luminaire. High-performance optics, uniform light emission, the possibility of using a DALI-based system allows for perfect lighting of the space around buildings, parks, sports and recreation facilities. In addition, luminaire can serve as a shelter for small animals by equipping it with a nesting box. Reet is not only an outdoor luminaire, but above all a support for animals in today’s urban world of people.



design: Ultra Architects

  • ip65
  • ik06
  • żyrandol
  • CE

Available product colors

Standard:
  • white
    03
  • grey
    06
  • anthracite
    70
  • black
    05

Lightsource: Conventional

E- elctronics
0- On- Off
D- DALI



C - colour

L - beam angle:
04 - park light

Catalogue code Luminaire light flux Power Color temperature CRI/RA Weight Dimensions Box dimensions
9212.03ELC 2844lm 25W 3000K ≥80 45kg without nest box 4020x220x220mm
9212.04ELC 2963lm 25W 4000K ≥80 45kg without nest box 4020x220x220mm
9213.03ELC 4083lm 38W 3000K ≥80 45kg without nest box 4020x220x220mm
9213.04ELC 4253lm 38W 4000K ≥80 45kg without nest box 4020x220x220mm
9212.13ELC 2844lm 25W 3000K ≥80 45kg with the nest box 4020x220x220mm
9212.14ELC 2963lm 25W 4000K ≥80 45kg with the nest box 4020x220x220mm
9213.13ELC 4083lm 38W 3000K ≥80 45kg with the nest box 4020x220x220mm
9213.14ELC 4253lm 38W 4000K ≥80 45kg with the nest box 4020x220x220mm
9212.23ELC 2844lm 25W 3000K ≥80 45kg with the nest box and the camera 4020x220x220mm
9212.24ELC 2963lm 25W 4000K ≥80 45kg with the nest box and the camera 4020x220x220mm
9213.23ELC 4083lm 38W 3000K ≥80 45kg with the nest box and the camera 4020x220x220mm
9213.24ELC 4253lm 38W 4000K ≥80 45kg with the nest box and the camera 4020x220x220mm
Expand

Photometric body

Photometric body
Photometric body
Photometric body
Photometric body
Photometric body

Accessories

foundation
code number: 1300.1000
foot cover
code number: 90.25C

Product data sheet

Select indexes and their data to appear on the PDF.

Generate PDF
Selected Catalogue code Luminaire light flux Power Color temperature CRI/RA Weight Dimensions Box dimensions
9212.03ELC 2844lm 25W 3000K ≥80 45kg without nest box 4020x220x220mm
9212.04ELC 2963lm 25W 4000K ≥80 45kg without nest box 4020x220x220mm
9213.03ELC 4083lm 38W 3000K ≥80 45kg without nest box 4020x220x220mm
9213.04ELC 4253lm 38W 4000K ≥80 45kg without nest box 4020x220x220mm
9212.13ELC 2844lm 25W 3000K ≥80 45kg with the nest box 4020x220x220mm
9212.14ELC 2963lm 25W 4000K ≥80 45kg with the nest box 4020x220x220mm
9213.13ELC 4083lm 38W 3000K ≥80 45kg with the nest box 4020x220x220mm
9213.14ELC 4253lm 38W 4000K ≥80 45kg with the nest box 4020x220x220mm
9212.23ELC 2844lm 25W 3000K ≥80 45kg with the nest box and the camera 4020x220x220mm
9212.24ELC 2963lm 25W 4000K ≥80 45kg with the nest box and the camera 4020x220x220mm
9213.23ELC 4083lm 38W 3000K ≥80 45kg with the nest box and the camera 4020x220x220mm
9213.24ELC 4253lm 38W 4000K ≥80 45kg with the nest box and the camera 4020x220x220mm
