Technical data

General data:

Casing:
aluminum
Mounting type:
surface mounted
Ingress protection IP:
IP20
Operating temperature range:
from -20°C to +40°C
Lifetime L80B10:
100 000h

Electrical data:

Nominal voltage:
220-240V AC
Nominal frequency:
50-60 Hz
Protection class:
I
Contains light source:
yes
Dimming:
on-off, DALI, CASAMBI

Optical data:

Optical system:
reflector
Material:
aluminum
Light distribution:
symmetrical
Light emission:
direct
Lenses available:
90°

Lighting data:

Light source:
LED
Colour rendering index:
CRI>90
Tolerance of luminous flux:
+/-10%
SDCM colour tolerance:
SDCM<3

Other data:

Weight:
3,5kg
Box:
400x400x280mm

Product description

Spin is a series of surface-mounted luminaires with a simple appearance, thanks to which they become an aesthetic architectural element of the designed space. They are ideal for installation on ceilings where it is not possible to use recessed luminaires. Luminaires available in three diameters (90mm, 120mm, 160mm, 230mm), using high-quality LEDs and an efficient aluminum reflector. In addition, the luminaires can be hung by adding hangers. Spin is an excellent solution for lighting shops, communication routes, office buildings and residential buildings.

  • ip
  • klasas
  • ce

Available product colors

Standard:
  • white
    03
  • black
    05
  • grey
    06
  • anthracite
    70

C- colour



E- electronic

O- on-off

D- DALI

C- CASAMBI



L- lens

90 – 90°


Catalogue code Luminaire light flux Power Effectiveness Color temperature UGR
4043.02ELC 4551lm 39W 127lm/W 2700K <22
4043.03ELC 4741lm 39W 127lm/W 3000K <22
4043.04ELC 4938lm 39W 127lm/W 4000K <22

Accessories

adapter for suspension 1500mm
40.05
adapter for suspension 4000mm
40.06
