Technical data
General data:
Luminaire body:
aluminum
Mounting type :
recessed
Ingress protection IP for 36W:
IP40/IP20
Ingress protection IP for 34W, 23W:
IP20
Operating temperature range :
from 0°C to +40°C
Lifetime L80B10 for 36W, 34W, 23W:
30000h, 35000h, 50000h
Impact protection IK :
IK02
Optical data:
Nominal voltage :
220-240 V
Nominal frequency :
50 Hz
Protection class :
II
Lighting data:
Optical system :
diffuser
Material :
PS
Light distribution :
symmetrical
Electrical data:
Colour rendering index :
CRI > 80
Colour tolerance SDCM :
< 5 SDCM
Downloads
.jpg)
.jpg)
.jpg)
.jpg)
| Catalogue code | Luminaire light flux | Power | Effectiveness | Color temperature | Beam angle | Box dimensions | UGR |
|---|---|---|---|---|---|---|---|
| EP0001.3 | 3600lm | 36W | 100lm/W | 3000K | 120° | 620x620x120mm | — |
| EP0001.4 | 3600lm | 36W | 100lm/W | 4000K | 120° | 620x620x120mm | — |
| EP0002.3 | 3600lm | 36W | 100lm/W | 3000K | 90° | 620x620x120mm | <19 |
| EP0002.4 | 3600lm | 36W | 100lm/W | 4000K | 90° | 620x620x120mm | <19 |
| EP0003.3 | 4080lm | 34W | 120lm/W | 3000K | 120° | 620x620x120mm | — |
| EP0003.4 | 4080lm | 34W | 120lm/W | 4000K | 120° | 620x620x120mm | — |
| EP0004.3 | 3944lm | 34W | 116lm/W | 3000K | 90° | 620x620x120mm | <19 |
| EP0004.4 | 3944lm | 34W | 116lm/W | 4000K | 90° | 620x620x120mm | <19 |
| EP0005.4 | 4255lm | 23W | 185lm/W | 4000K | 120° | 620x620x120mm | — |
| EP0006.4 | 4025lm | 23W | 175lm/W | 4000K | 90° | 620x620x120mm | <19 |
Accessories
Surface mounted set for 600X600 panels, H70mm
catalogue number EP01
Plasterboard ceiling mounting set (4 pcs)
catalogue number EP02
Suspension lines set (2 pcs) Y shape, 1,5m length, power supply not included
catalogue number EP03
