BRI Wallwasher

choose a luminaire variant ➔

surface mounted
suspended

Technical data

General data:

Luminaire body:

aluminum

Mounting type:

surface mounted

Ingress protection IP:

IP20

operating temperature range:

from -20° to +35°

lifetime L80B10:

100 000h

Electrical data:

nominal voltage:

230-240V AC

nominal frequency:

50-60Hz

protection class:

Contains light source:

yes

dimming:

DALI, Casambi, on-off

Optical data:

optical system:

reflector

Material:

light distribution:

asymmetrical

Lighting data:

colour rendering index:

CRI≥80 (on request: CRI≥90)

glare indicator UGR:

Type of source:

LED

Downloads

Product data sheet Assembly, use and maintance instructions Declaration of Conformity LDT files

Product description

BRI wallwasher is a luminaire with an asymmetrical, very wide light beam. Wallwasher luminaire uses a specially constructed reflector that reflects the light and directs it in a way that creates a bright beam of light in a place that we want to illuminate. It’s a perfect solution for large areas, where the lighting is necessary, but standard luminaires can’t be used, for example in auditoriums or museums where there is a need for pointing a light beam directly at a given object.

The luminaire is available in two mounting options: surface and suspended. The glare index is at the level of UGR<20. Luminaire power options are: 28W-2889lm, 54W-5777lm, 80W-8666lm. The available color temperatures are: 3000K/4000K – CRI ≥80.

Available product colors

Standard:

white

03
grey

06
anthracite

70
black

05

E- electronics

0- On-Off

D- DALI

C- Casambi

C - colour

Catalogue code	Luminaire light flux	Power	Effectiveness	Color temperature	CRI/RA	Dimensions	UGR
1105.043E.10C	2773lm	28W	103lm/W	3000K	≥80	L=1144mm	<20
1105.044E.10C	2889lm	28W	103lm/W	4000K	≥80	L=1144mm	<20
1105.083E.10C	5546lm	54W	107lm/W	3000K	≥80	L=2284mm	<20
1105.084E.10C	5777lm	54W	107lm/W	4000K	≥80	L=2284mm	<20
1105.123E.10C	8320lm	80W	108lm/W	3000K	≥80	L=	<20
1105.124E.10C	8666lm	80W	108lm/W	4000K	≥80	L=3424mm	<20

Catalogue code	Luminaire light flux	Power	Effectiveness	Color temperature	CRI/RA	Dimensions	UGR
1105.043E.10C	2773lm	28W	103lm/W	3000K	≥80	L=1144mm	<20
1105.044E.10C	2889lm	28W	103lm/W	4000K	≥80	L=1144mm	<20
1105.083E.10C	5546lm	54W	107lm/W	3000K	≥80	L=2284mm	<20
1105.084E.10C	5777lm	54W	107lm/W	4000K	≥80	L=2284mm	<20
1105.123E.10C	8320lm	80W	108lm/W	3000K	≥80	L=	<20
1105.124E.10C	8666lm	80W	108lm/W	4000K	≥80	L=3424mm	<20
