Technical data

General data:

Luminaire body:
aluminum
Mounting:
surfaced
Ingress protection IP:
IP20
Operating temperature range:
from -20° to +35°
Lifetime L80B10:
100 000h

Electrical data:

Nominal voltage:
230-240V AC
Nominal freguency:
50-60Hz
Protection class:
I
Contains light source:
yes
Dimming:
DALI, Casambi, on-off

Optical data:

Optical system:
lens
Lenses available:
50°, 80°

Lighting data:

Light source:
LED
Colour rendering index:
CRI≥80 (on request: CRI≥90)
Tolerance of luminous flux:
SDCM<3

Available product colors

Standard:
  • white
    03
  • grey
    06
  • anthracite
    70
  • black
    05

E- electronics

0- On-Off

D- DALI



L - optics

50 - 50°

80 - 80°

C - colour

Catalogue code Luminaire light flux Power Effectiveness Color temperature CRI/RA UGR
5016.04ELC 1833lm 13W 141lm/W 4000K ≥80 17
5016.03ELC 1759lm 13W 141lm/W 3000K ≥80 17
