Technical data
General data:
Luminaire body:
aluminum
Mounting type :
recessed
Ingress protection IP:
IP20
Electrical data:
Nominal voltage :
220-240V AC
Nominal frequency :
50-60Hz
Protection class :
I
Dimming :
on/off, DALI
Optical data:
Light emission :
direct
Light distribution :
symmetrical
Lighting data:
Light source :
LED
Downloads
Available product colors
Standard:
-
white03 -
grey06 -
anthracite70 -
black05
E- electronics
0- On-Off
D- DALI
L - lens
60 - 60°
30 - 30°
18 - 18°
C - colour
| Catalogue code | Luminaire light flux | Power | Effectiveness | Color temperature | Dimensions |
|---|---|---|---|---|---|
| 1026.062E.20LC | 1867lm | 18W | 104lm/W | 2700K | 1680mm |
| 1026.063E.20LC | 1755lm | 18W | 98lm/W | 3000K | 1680mm |
| 1026.064E.20LC | 1650lm | 18W | 92lm/W | 4000K | 1680mm |
| 1026.072E.20LC | 2443lm | 24W | 102lm/W | 2700K | 1960mm |
| 1026.073E.20LC | 2296lm | 24W | 96lm/W | 3000K | 1960mm |
| 1026.074E.20LC | 2158lm | 24W | 90lm/W | 4000K | 1960mm |
| 1026.082E.20LC | 3020lm | 31W | 97lm/W | 2700K | 2240mm |
| 1026.083E.20LC | 2839lm | 31W | 92lm/W | 3000K | 2240mm |
| 1026.084E.20LC | 2669lm | 31W | 86lm/W | 4000K | 2240mm |
