Technical data
General data:
Mounting type:
suspended
Luminaire body:
steel
Ingress protection IP:
20
Electrical data:
Nominal voltage:
220-240V AC
Nominal freguency:
50-60Hz
Protection class:
I
Dimming:
ON-OFF, DALI Casambi
Optical data:
Optical system:
microprism diffuser
Light distribution:
symmetrical
Light emission:
direct
Lighting data:
contains light source:
yes
Light source:
LED
Colour rendering index:
CRI>80 (on request: CRI>90)
Colour tolerance SDCM:
SDCM<3
Tolerance of luminous flux:
+/-10%
Product description
Sir Platter is a simple and elegant form combined with appropriate optics, ensuring the highest comfort of work and staying in the room. The luminaire provides even illumination without glare effect- glare factor UGR<19 (4H8H). Thanks to luminance <3000 dc/m2 luminaire Sir Platter is the perfect solution in very demanding office space. The additional advantage is easy and quick instalation without the need to open the body of the luminaire. The luminaire is also available in a surface-mounted version.
Available product colors
Standard:
-
white03 -
grey06 -
anthracite70 -
black05
suspension cabels certified fot resistance to vibrations and oscillations
E- electronics
0- On-Off
D- DALI
C- Casambi
C- colour
| Catalogue code | Luminaire light flux | Power | Effectiveness | Color temperature | UGR |
|---|---|---|---|---|---|
| 601123.EC | 10092lm | 74W | 143lm/W | 3000K | <19 |
| 601124.EC | 10612lm | 74W | 146lm/W | 4000K | <22 |
| 602123.EC | 20922lm | 151W | 146lm/W | 3000K | <22 |
| 602124.EC | 22000lm | 151W | 146lm/W | 4000K | <22 |
Accessories
Central ceiling rose Ø200
catalogue number 60.02C
