Technical data
General data:
Luminaire body:
steel
Mounting type:
suspended
Ingress protection IP:
IP20
Operating temperature range:
od -20° do +35°
Lifetime L80B10:
100 000h
Electrical data:
Nominal voltage:
230-240V AC
Nominal freguency::
50-60Hz
Protection class:
I
Dimming:
ON-OFF, DALI
Optical data:
Optical system:
microprismatic diffuser
Material:
PMMA
Light emission:
direct- indirect
Lighting data:
Light source:
LED
Colour rendering index:
CRI>80 (on request: CRI>90)
Colour tolerance SDCM:
SDCM<3
Tolerance of luminous flux:
+/-10%
Colour temperature:
3000K,4000K
Downloads
Product description
The Sir Platter Up&Down luminaire is a high-end lighting solution with precise photometric parameters, designed for professional use in commercial and public interiors. It emits light in two directions (upward and downward), ensuring even illumination of the space while minimizing glare—its low UGR<17 rating ensures visual comfort, which is particularly important in work and utility areas. The luminire features a modern LED light source with high luminous flux and is available in various color temperatures 3000K, 4000K, allowing for precise adjustment of light color.
Available product colors
Standard:
-
white03 -
grey06 -
anthracite70 -
black05
| Catalogue code | Luminaire light flux | Power | Effectiveness | Color temperature | UGR |
|---|---|---|---|---|---|
| 6130.123EC | 15072lm | 107W | 141lm/W | 3000K | <18 |
| 6130.124EC | 16034lm | 107W | 150lm/W | 4000K | <18 |
| 6131.123EC | 26008lm | 184W | 141lm/W | 3000K | <20 |
| 6131.124EC | 27668lm | 184W | 150lm/W | 4000K | <20 |
Accessories
Central ceiling rose Ø200
catalogue number 60.02C
